Grates are ADA compliant
Grates are reversible from a flat side to a 3/16" convex side
Trench drain & grate come in 48" (4 feet) sections that can be cut down to 12", 24" & 36"
Lock tab feature for proper alignment and stability
Two #8 screws are used to interlock ends together
All outlet ports accept 3" SCHD 40 pipe, 4" SDR 35 pipe & 4" SCHD 40 pipe Optional open end caps are available and will accept various size pipe Optional closed end caps are also available
Both end caps will fit either end of the trench drain
Outside holes accept #4 rebar for fast positioning
2x4's can be easily fastened to the base to provide a wider footing
Grate is fastened to trench drain base with provided #8 x 1-1/4" screws
Cut lines are indicated at every foot (12", 24" & 36")
Cut ends attach with lock tab feature and two #8 screws
H-20 wheel load rating when cast in reinforced concrete
NOTE: Traffic speed not to exceed 20 mph. Not recommended for forklift traffic.
