ICM's 1500 Series Intermittent Ignition Oil Primary Controls come standard with patented energy transfer technology that ensures the fuel valve and pump will only be energized if the control is functioning properly. Features a solid state flame sensing circuit, LED to indicate system lockout, an enclosed safety switch and an external reset button. Direct replacement for popular competitive models.
Product Features
Controls oil burner, oil valve (if desired) and the ignition transformer in response to a call for heat
Solid state flame sensing circuit
LED on terminal strip indicates system lockout
Enclosed safety switch with external reset button
Mounts on standard 4 x 4 in. junction box; select models may be mounted directly on burner housing
C554A Cadmium Sulfide Flame Detector and 24 VAC thermostat required
Direct replacement for popular competitive models
Replaces:
Honeywell: R8184G4009, R8184G1138, R8184G1427, R8184G4025
Carlin: 48245
Tempstar/Heil: 1147017
White Rodgers: 668-401
